Atlas Copco WEDA D30N Submersible Dewatering Pump
HP3PhaseSingle-Phase / Three-Phase
$2,430.00
SKU
3081620491
Downloads & Resources
- Processed next business day
- Authorized dealer
- Service support
The Atlas Copco WEDA D30N is a 3 HP heavy-duty submersible dewatering pump with a 3" NPT discharge, CSA-certified for professional contractor and rental fleet use. Standard-head (N) impeller balances head and flow for general site dewatering.
Key Features
- 3 HP submersible motor
- 220 GPM max flow / 92 ft max head (1-phase); 210 GPM / 85 ft (3-phase)
- 3" NPT discharge connection
- 0.28" max solid pass-through
- Atlas Copco's US SKU description specifies CSA.
- Multiple voltage options — see variants below
Ideal Applications
- Construction site dewatering
- Mining and tunneling water removal
- Flood and basement pump-out
- Wellpoint and pond transfer
- Industrial sump and process water
Specifications
| Model | WEDA D30N |
|---|---|
| Impeller / Head Class | standard |
| Horsepower | 3 HP |
| Max Flow | 220 gpm (1-phase) / 210 gpm (3-phase) |
| Max Head | 92 ft (1-phase) / 85 ft (3-phase) |
| Shaft Speed | 3500 rpm |
| Rated Output | 2.2 kW |
| Max Power Input | 2.9 kW |
| Discharge | 3" NPT |
| Max Solids | 0.28" |
| Weight | 44 lb |
| Height | 19.5 in |
| Diameter | 8.7 in |
| Warranty | 12 months from start-up / 18 months from receipt (whichever comes first) |
Why Buy From A1 Compressor Warehouse
- Authorized Atlas Copco dealer — full factory warranty support.
- Free application sizing — call (803) 526-5797 or email sales@a1compressorwarehouse.com before you order.
- Same-day quotes* on requests received before 3 PM ET. Next-business-day order processing.
- Direct-to-consumer pricing — no middleman markup.
*Same-day quote applies to requests received before 3 PM ET.
Specifications
| Brand | Atlas Copco |
|---|---|
| Model # | WEDA D30N |
| Mfr Part # | 3081620491 |
| Horsepower | 3 HP |
| Voltage | 220V / 240V / 460V |
| Phase | Single-Phase / Three-Phase |
| Weight | 44 lb |
| Warranty | 12 months from start-up / 18 months from receipt (whichever comes first) |
Shipping & Returns
We process most orders within one business day. Freight items ship by motor carrier — we'll coordinate delivery for residential and limited-access addresses.
- Nationwide shipping. Call (803) 526-5797 for a freight quote on large equipment.
- All sales final. Please confirm fitment, specifications, and compatibility before ordering — contact us if you need a sizing consult.
- Manufacturer warranty applies — see spec sheet or contact us with your serial number.
