Atlas Copco WEDA D10N Submersible Dewatering Pump

The Atlas Copco WEDA D10N is a 1.5 HP heavy-duty submersible drainage pump with a 2" NPT discharge. CSA-certified for professional dewatering: utility excavations, slurry pits, and general construction site water removal.

Key Features

• 1.5 HP submersible motor
• 134 GPM max flow / 53 ft max head
• 2" NPT discharge connection
• 0.16" max solid pass-through — handles trash water
• Atlas Copco's US SKU description specifies CSA.
• Multiple voltage options — see variants below

Ideal Applications

• Construction site dewatering
• Mining and tunneling water removal
• Flood and basement pump-out
• Wellpoint and pond transfer
• Industrial sump and process water

Specifications

About the WEDA D10N

The Atlas Copco WEDA D10N removes clean or dirty water from construction sites, mines and quarries with a choice of single-phase or three-phase configurations. Its submersible layout lets the pump work directly in a sump without a surface-pump priming arrangement. The motor size provides a step up in flow from the D08N while retaining a small discharge connection and similar pump weight. Choose the electrical version to suit the site's supply, then use that version's hydraulic figures to match the pump to the discharge route.

How the WEDA D10N compares

The 1.5 HP D10N increases flow capacity over the 1 HP WEDA D08N, whose maximum flow is 66 gpm. In single-phase form, the D10N reaches 134 gpm maximum flow and 53 ft maximum head, while the larger 3 HP WEDA D30L reaches 390 gpm maximum flow in single-phase form. For each model in the WEDA pump range, maximum flow and maximum head are not reached at the same time; check the curve for your required flow and lift.

Questions about the WEDA D10N

Which voltage and phase can I choose?

The listed choices are 115V single-phase, 220–240V single-phase and 460V three-phase, all at 60 Hz. Select the version that matches the electrical supply at the installation.

How heavy is it, and what discharge does it use?

The D10N weighs 29 lb and has a 2 inch discharge. Check that the pump and discharge line fit the intended position.

Can it handle mining water?

The D family covers mining and quarry drainage, and the D10N has a 0.16 inch solids limit. Check the solids in the water against that limit before choosing the pump.
