Atlas Copco WEDA D04N submersible dewatering pump (WEDA 04 range photo)
Atlas CopcoModel #: WEDA D04N

Atlas Copco WEDA D04N Submersible Dewatering Pump

HP0.5PhaseSingle-Phase
$350.00
SKU 8162172700
Orders processed next business day.

Ship dates vary by vendor and can change.

Preferred for freight or configured items

Downloads & Resources

Download Spec Sheet (PDF)
  • Processed next business day
  • Authorized dealer
  • Service support

The Atlas Copco WEDA D04N is a 0.5 HP submersible drainage pump for light dewatering — basements, pits, and small site puddles. 2" NPT discharge, 0.3" max solids handling.

Key Features

  • 0.5 HP submersible motor
  • 61 GPM max flow / 39 ft max head
  • 2" NPT discharge connection
  • 0.3" max solid pass-through
  • Atlas Copco's US SKU description specifies UL.
  • Offered configuration: 115 V, 60 Hz, single phase (SKU 8162172700).

Ideal Applications

  • Construction site dewatering
  • Mining and tunneling water removal
  • Flood and basement pump-out
  • Wellpoint and pond transfer
  • Industrial sump and process water

Specifications

Model WEDA D04N
Impeller / Head Class standard
Horsepower 0.5 HP
Max Flow 61 gpm
Max Head 39 ft
Shaft Speed 3500 rpm
Rated Output 0.4 kW
Max Power Input 0.7 kW
Discharge 2" NPT
Max Solids 0.3"
Weight 20 lb
Height 13.4 in
Diameter 7.2 in
Voltage 115V
Phase Single-Phase
Warranty 12 months from start-up / 18 months from receipt (whichever comes first)
