Mattei RVD 7 / RVD 11 Direct-Drive Fixed-Speed Rotary Vane Compressor (10–15 HP)
HP10CFM40PSI138 (145 ver)Tank80 gallonPhaseThree-Phase
$17,069.45
SKU
1400000252
- Ships in 24 hrs
- Authorized dealer
- Service support
Mattei rotary vane technology is the gold standard for continuous-duty industrial compressed air. With a single moving rotor (no contact between vanes and stator), Mattei compressors typically deliver 80,000+ hours to first overhaul — three to four times the service life of a comparable rotary screw machine, with lower vibration, quieter operation, and steadier flow.
The Mattei RVD 7 / RVD 11 is a direct-drive, fixed-speed rotary vane compressor — the higher-flow successor to the BLADE 7-11. Equipped with air aftercooler, MAESTRO XB control & protection, star-delta starter, Rotoroil F2 oil fill, and IE3 high-efficiency motor. Available in 6 layouts: skid base, +refrigerated dryer, +80gal tank, +120gal tank, +80gal+dryer, or +120gal+dryer.
Specifications
| Power | 10 HP / 7.5 kW (RVD 7) • 15 HP / 11 kW (RVD 11) |
| Flow @ 145 PSI | 40.2 ACFM (RVD 7) • 54.7 ACFM (RVD 11) |
| Power Supply | 208V / 230V / 460V — 60 Hz / 3-Phase |
| Drive | Direct drive (direct coupling) |
| Dimensions (base) | 46 × 30 × 39 in |
| Weight | 595–1,267 lb (depends on config) |
| Sound Level | 66 dB(A) |
| Air Outlet | 1 in |
| Motor | IE3 high-efficiency |
| Working Pressure | 138 PSI (145 ver) |
| Country of Origin | Italy |
Optional Upgrades (Field-Installed)
These factory-supported options can be added to your order — call us to configure.
| Upgrade | Mattei Code | Add to Price |
|---|---|---|
| Condensate drain & separator kit (RVD 7) | 30005287 | $485 |
| Condensate drain & separator kit (RVD 11) | 30005288 | $493 |
| Cabinet heater kit (+14°F ambient) | 30001711 | $1888 |
| V-Life Food Lubricant | — | $395 |
Why buy from A1 Compressor Warehouse
- Authorized Mattei distributor — full factory warranty
- Free pre-purchase consultation: call us or email sales@a1compressorwarehouse.com
- Same-day response to inquiries; 24-hour order processing
- Service support and OEM Mattei maintenance kits stocked
Specifications
| Brand | Mattei |
|---|---|
| Model # | 1400000252 |
| Mfr Part # | 1400000252 |
| Horsepower | 10 HP |
| CFM | 40 |
| Max Pressure | 138 PSI (145 ver) |
| Tank Size | 80 gallon |
| Voltage | 208V / 230V / 460V |
| Phase | Three-Phase |
| Noise | 66 dB(A) |
| Weight | 595–1,267 lb (depends on config) |
| Dimensions | 46 × 30 × 39 in |
| Country of Origin | Italy |
Shipping & Returns
We process most orders within one business day. Freight items ship by motor carrier — we'll coordinate delivery for residential and limited-access addresses.
- Nationwide shipping. Call (803) 693-2350 for a freight quote on large equipment.
- All sales final. Please confirm fitment, specifications, and compatibility before ordering — contact us if you need a sizing consult.
- Manufacturer warranty applies — see spec sheet or contact us with your serial number.
