MatteiModel #: 12-H-PRIMER

Mattei ASME Air Receiver Tank — Horizontal or Vertical (12–3,000 gallons)

Name: Mattei ASME Air Receiver Tank — Horizontal or Vertical (12–3,000 gallons)
Brand: Mattei
SKU: 12-H-PRIMER

PSI150–200g (depending on size)Tank12 gallon

$908.00

SKU 12-H-PRIMER

Processed next business day
Authorized dealer
Service support

Mattei Air Receiver Tanks — ASME-stamped compressed-air storage from 12 to 3,000 gallons, in horizontal or vertical orientation, primer-coated or fully painted finish. Air receiver tanks improve operation and energy efficiency of your compressed-air system. Having 3 gallons/CFM of storage vs 1 gallon/CFM equates to a ~10% reduction in energy costs. More air storage is better!

Specifications

Capacity Range	12–3,000 gallons
Max Working Pressure	150–200 psig (depending on size)
Standards	ASME-stamped
Standard Equipment	Safety pressure-relief valve, pressure gauge
Notes	12 & 20 gal: 4 pressed steel feet. Other horizontals: channel feet. Vertical 30–240 gal: legs. Vertical 400+: base rings.
Painted Finish	Exterior powder coated
Country of Origin	Italy

Larger sizes (1,550+ gal) painted versions are quote-only — call us.

Why buy from A1 Compressor Warehouse

Authorized Mattei distributor — full factory warranty
Free pre-purchase consultation: call us or email sales@a1compressorwarehouse.com
Same-day response to inquiries; next-business-day order processing
Full Mattei replacement element catalog

Specifications

Brand	Mattei
Model #	12-H-PRIMER
Max Pressure	150–200 psig (depending on size)
Tank Size	12 gallon
Country of Origin	Italy

Specifications by model

Model / Option	Tank Size	Price
12 gal / Horizontal / Primer Coated	12 gallon	$908.00
12 gal / Horizontal / Painted	12 gallon	$1,254.40
20 gal / Horizontal / Primer Coated	20 gallon	$890.40
20 gal / Horizontal / Painted	20 gallon	$1,296.00
30 gal / Horizontal / Primer Coated	30 gallon	$1,114.40
30 gal / Horizontal / Painted	30 gallon	$1,590.40
60 gal / Horizontal / Primer Coated	60 gallon	$1,312.00
60 gal / Horizontal / Painted	60 gallon	$1,824.00
80 gal / Horizontal / Primer Coated	80 gallon	$1,612.00
80 gal / Horizontal / Painted	80 gallon	$2,148.00
120 gal / Horizontal / Primer Coated	120 gallon	$2,334.40
120 gal / Horizontal / Painted	120 gallon	$2,930.40
240 gal / Horizontal / Primer Coated	240 gallon	$3,766.40
240 gal / Horizontal / Painted	240 gallon	$4,528.00
30 gal / Vertical / Primer Coated	30 gallon	$968.00
30 gal / Vertical / Painted	30 gallon	$1,398.40
60 gal / Vertical / Primer Coated	60 gallon	$1,268.00
60 gal / Vertical / Painted	60 gallon	$1,768.00
80 gal / Vertical / Primer Coated	80 gallon	$1,526.40
80 gal / Vertical / Painted	80 gallon	$2,062.40
120 gal / Vertical / Primer Coated	120 gallon	$1,826.40
120 gal / Vertical / Painted	120 gallon	$2,482.40
200 gal / Vertical / Primer Coated	200 gallon	$2,976.00
200 gal / Vertical / Painted	200 gallon	$3,690.40
240 gal / Vertical / Primer Coated	240 gallon	$3,020.00
240 gal / Vertical / Painted	240 gallon	$3,782.40
400 gal / Vertical / Primer Coated	400 gallon	$4,574.40
400 gal / Vertical / Painted	400 gallon	$5,468.00
500 gal / Vertical / Primer Coated	500 gallon	$7,084.00
500 gal / Vertical / Painted	500 gallon	$8,024.00
660 gal / Vertical / Primer Coated	660 gallon	$11,364.00
660 gal / Vertical / Painted	660 gallon	$12,496.00
1060 gal / Vertical / Primer Coated	1060 gallon	$16,422.40
1060 gal / Vertical / Painted	1060 gallon	$17,744.00
1550 gal / Vertical / Primer Coated	1550 gallon	$24,864.00
2000 gal / Vertical / Primer Coated	2000 gallon	$29,586.40
2560 gal / Vertical / Primer Coated	2560 gallon	$32,782.40
3000 gal / Vertical / Primer Coated	3000 gallon	$40,968.00
