Atlas Copco Rivet Busters: How to Choose the Right Model

Two specs decide which Atlas Copco rivet buster you need, and price is not one of them. Cylinder length sets how hard the tool hits. Handle type sets how you hold it and where the trigger sits. Everything else across the line is common: the same Jumbo shank, the same 44.5 CFM of air, the same job of shearing rivets and bolts off steel and breaking concrete. More buyers call us asking which rivet buster to order than about any other tool in the Atlas Copco lineup, so here is the whole decision in one place.

Rivet Gun or Rivet Buster? Same Tool

In demolition work the two names get used interchangeably, and when someone calls us asking about a rivet gun this is the tool they want. It is worth naming the other meaning once so nobody orders the wrong thing. A riveting hammer sets rivets, which is aircraft and structural fabrication work. A rivet buster removes them. Everything below is about removing them.

Atlas Copco builds these for removing rivets in metal and concrete applications, including demolition and bridge work. The buyers we see are demolition contractors and utility and municipal crews, which is the same customer base buying breakers and Cobra units out of the rest of the Atlas Copco pneumatic tool line. Typical work is shearing rivets and bolts off old steel, bridge deck rehab, cutting tanks, and horizontal demolition where a breaker is the wrong shape for the job.

The Two Decisions That Matter

Atlas publishes full data on the TEX 14 and TEX 15 pair, and that table shows the whole decision clearly.

	TEX 14	TEX 14 D	TEX 15	TEX 15 D
Cylinder	Short (8")	Short (8")	Long (11")	Long (11")
Impact rate	900 blows/min	900 blows/min	720 blows/min	720 blows/min
Handle	Open	D	Open	D
Trigger	Outside	Inside	Outside	Inside
Weight	13.7 kg	14.1 kg	15 kg	15.4 kg
Length	584 mm	600 mm	660 mm	676 mm
Air consumption	21 l/s	21 l/s	21 l/s	21 l/s
Vibration (ISO 20643)	12.6 m/s²	12.3 m/s²	13.3 m/s²	14.3 m/s²
Chuck	Jumbo	Jumbo	Jumbo	Jumbo
Part number	8461 0250 16	8461 0250 17	8461 0250 18	8461 0250 19

Notice what does not change. Air consumption is identical at 21 l/s across all four, and every one of them takes the same Jumbo chuck. You are not trading air or tooling when you pick a model, which means the choice comes down to cylinder length and handle alone.

8 Inch or 11 Inch: Speed Against Force

The short cylinder tools hit 900 times a minute. The long cylinder tools hit 720 times a minute. That is not a downgrade, because the longer cylinder gives the piston more room to accelerate and lands a heavier blow each time it strikes.

The practical read is straightforward. Choose the 8 inch cylinder when you are removing a lot of fasteners and want strikes to land quickly, since the faster rate and the lighter tool both work in your favor over a full shift. Choose the 11 inch cylinder when individual rivets or sections are stubborn enough that raw blow energy matters more than how fast the tool cycles. The weight difference is real but modest at roughly 1.3 kg between the extremes.

In A1's Atlas Copco pneumatic tool catalog, the 8 inch class is the TEX 14 and the TEX 830. The 11 inch class is the TEX 15 and the TEX 1133. The TEX 626 is the 6 inch option when you want the lightest tool in the family.

What R, RP, and D Actually Mean

This is the part no spec sheet spells out, and it is why two models at the same price look identical on a product page. The suffix is the handle.

• TEX 14 and TEX 15: the plain model is the open handle with the trigger on the outside. The D model is the D-handle with the trigger inside the handle.
• TEX 626, TEX 830, and TEX 1133: R is the D-handle version. RP is the open handle version, with the P standing for pistol.
• The leading digits are the cylinder length. 626 is 6 inch, 830 is 8 inch, 1133 is 11 inch.

Within each pair the price is the same, so there is no budget argument here and you should pick on how the crew works. The D-handle puts the trigger inside the grip where it is shielded from accidental actuation, and it gives you a solid two hand hold for controlled downward work. The open handle is the lighter, more open configuration and it is easier to maneuver in tight quarters or at odd angles.

One honest note on the data. Atlas publishes the full performance table above for the TEX 14 and TEX 15 pair. For the TEX 626, 830, and 1133 we can confirm cylinder length and handle configuration from Atlas part numbers, but we are not going to publish blow rates or weights for those models that Atlas has not published itself. If you need those figures for a spec submittal, call us and we will get them from Atlas rather than guess.

Vibration Is the Spec Nobody Checks

Rivet busters are hard on hands, and the catalog data makes that concrete. The four models above measure between 12.3 and 14.3 m/s². For comparison, inside the same Atlas Copco handheld tool book, the vibro-reduced light and medium breakers measure roughly 3.7 to 5.7 m/s², and the TEX 05PE pneumatic hammer comes in at 2.4 m/s².

That is roughly triple the vibration of the reduced-vibration breakers sitting a few pages away in the same catalog, and the reason is simple: Atlas lists vibro-reduction as a feature on those breakers, and the rivet buster table has no such row. These tools do not have it. If your crew is running one all day, that number drives how long they can safely stay on the tool, and it is worth checking against your own exposure limits before you buy.

There is one useful wrinkle in the numbers. The TEX 14 D is the lowest of the four at 12.3 m/s² and the TEX 15 D is the highest at 14.3. If daily exposure is a live concern for your crew, the shorter tool is measurably kinder to the operator.

What It Takes to Feed One

Each of these tools pulls 21 l/s, which is about 44.5 CFM at working pressure. That is per tool, and it is a real number that catches people out. One rivet buster needs a serious air supply, and two crews running simultaneously puts you near 90 CFM before you have accounted for hose losses or anything else on the manifold.

For jobsite work that generally means a towable compressor rather than anything you would roll around a shop, and if you are sizing one from scratch our portable compressor sizing guide walks through the arithmetic. We also carry portable compressors for lighter duty. If you are not sure what your existing machine can actually deliver at pressure, that is exactly the kind of question our team answers for free.

Shanks, Cutters, and Wear Parts

Every rivet buster in the line takes the Jumbo chuck, which is the industry standard Jumbo shank. That is genuinely convenient, because it means cutters, flat and ripper chisels, moil points, and backout punches carry across the whole family. Buy a second tool later in a different cylinder length and your existing tooling still fits.

We do not list the cutters on the site, but we can source Jumbo shank tooling through Atlas Copco alongside the tool. Call or send us your list and we will quote it with the machine. The same goes for wear parts and rebuild components, which is the same parts sourcing we do on older Atlas Copco equipment every week.

A Word on Availability

Be aware that rivet busters are supply constrained. Demand is strong and Atlas Copco allocates what dealers can get, so availability on any given model moves week to week. We would rather tell you that up front than let you assume a listing means a box on a shelf.

Call or request a quote and we will tell you what is genuinely available right now and what the lead time looks like on anything that is not. As an authorized Atlas Copco dealer we are working from real allocation information rather than guessing, which is worth something on a tool that is hard to find. If you are weighing dealers generally, we wrote about what actually separates one Atlas Copco distributor from another.

Frequently Asked Questions

Is a rivet gun the same thing as a rivet buster?
In demolition and steel work, yes. A rivet buster removes rivets and bolts. The other tool that shares the name is a riveting hammer, which sets rivets in fabrication work, and that is a different machine for a different job.

What is the difference between the TEX 14 and the TEX 15?
Cylinder length. The TEX 14 has the short 8 inch cylinder and hits 900 times a minute. The TEX 15 has the long 11 inch cylinder and hits 720 times a minute with more energy per blow. The TEX 15 is also about 1.3 kg heavier.

What does the R or RP mean on a TEX 830 or TEX 1133?
It is the handle. R is the D-handle version with the trigger inside the handle. RP is the open pistol handle with the trigger outside. Both cost the same, so choose on ergonomics.

What size compressor do I need to run a rivet buster?
Budget about 44.5 CFM per tool at working pressure. A single tool needs a substantial portable or towable compressor, and running two at once puts you near 90 CFM before hose losses.

Do Atlas Copco rivet busters have vibration reduction?
No. Atlas lists vibro-reduction on much of its breaker range but not on the rivet busters, and the measured figures of 12.3 to 14.3 m/s² reflect that. Factor it into how long operators stay on the tool.

Not Sure Which One You Need? Ask Us.

Most of the rivet buster calls we take are somebody who knows the job but not the model number, and that is a five minute conversation, not a research project. Tell us what you are cutting and how the crew works, and we will tell you which cylinder length and handle to order and what we can actually get you.
